Projection System
RGB LCD Light Valve Projection System
Projection Direction
360° Projection
Main Component Technical Parameters
LCD Panel
Size: 0.67 inches
Driving Mode: Polycrystalline Silicon TFT Active Matrix
Pixel Count: 2,304,000 dots (1920 x 1200) x 3
Resolution: 1920 x 1200
Aspect Ratio: 16:10
Refresh Rate: 192Hz - 240Hz
Lens
Type: Optical Zoom (Manual) / Focus (Manual)
F-Fluff: 1.5 - 1.7
Focal Length: 20.0mm - 31.8mm
Zoom Ratio: 1 - 1.6
Lens Shift: Vertical: -50% to +50% (Horizontal Centering)
Horizontal: -20% to +20% (Vertical Centering) (Manual)
Light Source
Type: Laser Diode
Light Source Lifespan*1: 20,000 Hours (Lighting Mode: Standard/Quiet)
30,000 hours (Lighting Mode: Extended)
Projection Size (Distance)
Throw Ratio (Standard Lens)
1.35 - 2.20
Screen Size (Projection Distance, Zoom: Wide, Telephoto)
50" to 500" [1.44 m to 14.76 m]
Brightness Output*2*3
Normal
8,700 lumens*6 (Center)
8,000 lumens (Coloring Mode: Dynamic, Zoom: Wide, Lens Shift: Vertical Center/Horizontal Center)
Quiet/Extended
5,600 lumens (Coloring Mode: Dynamic, Zoom: Wide, Lens Shift: Vertical Center/Horizontal Center)
Custom
8,000 lumens - 5,600 lumens (Color Mode: Dynamic, Zoom: Wide, Lens Shift: Vertical Center/Horizontal Center)
Color Brightness Output*2*3
8,000 lumens (Color Mode: Dynamic, Zoom: Wide, Lens Shift: Vertical Center/Horizontal Center)
Contrast Ratio*2*3
Over 5,000,000:1
Color Reproduction
Up to 1.07 billion colors
Color Processing
10-bit
Built-in Speaker
Sound Output
10W Mono
A/V Mute
Supports Direct USB Playback
Supports Adjustment Functions
Color Modes: Dynamic, Performance, Cinema, sRGB, DICOM SIM, BT.709, Natural, Multi-screen Projection
Custom Gamma Adjustment
9-point Gamma Curve Adjustment
RGBCMY Correction
Adjustable Hue/Saturation/Brightness of RGBCMY
Scene-Adaptive Gamma Adjustment
Supports Easy-to-Use Functions
Vertical Keystone Correction
-30° to +30° (Zoom: Telephoto) Horizontal Keystone Correction -30° to +30° (Zoom: Telephoto) Quick Four-Corner Adjustment Supported Curve Correction Supported Dot Correction Supported Split-Screen Projection Supported Automatic Source Search Supported Schedule Setting Supported Screen Mirroring Supported NFC Supported HDR Supported Detail Enhancement Supported Super Resolution Supported Presentation Management Epson iProjection Supported Epson Projector Management Supported Epson Projector Professional Tool Supported Epson Projector Content Manager Supported Video Input/Output Inputs HDMI: 2
HD-BaseT: 1 Outputs HDMI: 1 Audio Input/Output Outputs Mini Stereo: 1 Control Signal Input/Output RS-232C D-sub 9pin: 1 USB Input/Output Type A 2 (1 of which is a 5V/2A power supply port) Type B
1 Network Input/Output
Wired LAN
RJ-45:1
Wireless LAN
Built-in
Operating Temperature
0℃ to 45℃ (Low Altitude: 0m - 2,286m)
0℃ to 40℃ (High Altitude: 2,286m - 3,048m) (20% - 80% Humidity, Non-condensing)
* Automatic dimming when ambient temperature is too high
Operating Altitude
0m to 3,048m (Over 1,500m: High Altitude Mode)
Dust Filter
Maintenance Cycle
20,000 hours* (Standard Mode/Quiet Mode 25℃)
30,000 hours* (Extended Mode/25℃)
* Based on basic office environment (sludge concentration: 0.04 - 0.2 mg/m3)
* Based on Epson indoor testing results
Power Supply Voltage
100 - 240 V AC +/- 10%, 50/60 Hz
Power Consumption
Voltage 220-240V
Standard Mode: 449W
Energy Saving Mode: 337W
Network Standby (Communication On): 2W
Energy Saving Standby: 0.5W
Rated Voltage and Current
100 - 240 V AC 50/60 Hz 3.8 - 1.6 A
Dimensions
Without support feet (W x H x D)
440 x 122 x 304mm
Maximum Dimensions (W x H x D)
440 x 138 x 339mm
Weight
9.5kg
Fan Noise
Standard Power Consumption
37dB
Energy Saving Power Consumption
28dB
Accessories
Power Cord
3m
Remote Control
Yes
Batteries
AA x 2
Cable Cover
Yes
User Manual
Yes
Optional Accessories
Air Filter
ELPAF65
External Camera
ELPEC01
HDBaseT Transmitter
ELPHD01
