Throw Ratio 1.09–2.21:17 (Corresponding value. When used together with optical zoom.)
Lens shift (From the origin point of the lens mounter)
Vertical
+44 %
Horizontal
±20 %
Keystone correction range
Vertical ±25 %, Horizontal ±35 %
Terminals
HDMI™ 1/2 IN
HDMI™ 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p8 signal input), CEC supported9
COMPUTER IN
D-sub 15-pin (female) (RGB/YPBPR/YCBCR)
AUDIO IN
M3 stereo mini-jack x 1
AUDIO OUT
M3 stereo mini-jack x 1
SERIAL IN
D-sub 9-pin (female) x 1 for computer control (RS-232C compliant)
DIGITAL LINK/LAN
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2], HDCP, Deep Color, 4K/30p8 signal input)
LAN
RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink™ [Class 2]
USB (VIEWER/ WIRELESS/DC OUT)
USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A10)
Protocol versions
IPv4, IPv611
Power supply
AC 100 –240 V, 50/60 Hz
Maximum power consumption12
400 W (4.2 A ) (405 VA) (Power consumption is 385 W at 200–240 V)
345 W (3.6 A) (350 VA) (Power consumption is 335 W at 200–240 V)
